Mid pressure sulfur tolerant shift catalyst

1)High-mid pressure, wide temperature range and wide water/gas ratio sulfur tolerant shift process.

2)High pressure and low water/gas ratio sulfur tolerant shift process.

3)High pressure, high temperature range, high water/gas ratio and low sulfur content sulfur tolerant shift process.

4)AMC-NB-07B is used in dust-absorption, detoxication protective bed, AMC-NB-07T is used in deoxidation and detoxication process.

Inquire Now Next Product

Product introduction

1) Co-Mo/TiO₂-MgO-Al₂O₃ based sulfur tolerant shift catalyst with TiO2 improved dispersion and sulfiding performance of active components Co-Mo, as well as catalyst shift activity under the conditions of low temperature and low sulfur content.

2) The additives of blended rare earth improve the activity and stability , as well as inhibit the side reactions of methanation and F-T synthesis.

3) AMC-NB-07B has dust absorption function and generally used in protective bed. AMC-NB-07T has deoxidation and detoxication functions and used in deoxidant bed.

4) Excellent adaptability to high space velocity and high water/gas ratio, good operating flexibility; good hydration resistance; high mechanical strength; strong resistance to poison and long service life.

5) Excellent performance of organic sulfur hydrogenolysis and cyanide removal.

6) Patented product and awarded the National Prize for Science and Technology Progress.

Product Basic Info

Operating Conditions:

Temperature/℃	200~500
Pressure/MPa	2.0~10.0
Space Velocity(dry based)/h^-1	1000~6000
Water gas ratio	0.2~1.8
Sulfur content in process gas,%(v)	≥0.01

Product Specification

Item	AMC-NB-07	AMC-NB-07B	AMC-NB-07T
Color and shape	Sage green extrudate	Sage green extrudate	Sage green extrudate
Size/mm	Φ3.5~4.0	Φ3.5~4.0	Φ3.5~4.0
Active components	Co-Mo	Co-Mo	Co-Mo
Bulk density/(kg·L^-1)	0.80~0.90	0.88~0.98	0.80~0.90
Crushing strength(N·cm^-1)	≥120	≥120	≥120
Carriers	TiO2-MgO-Al2O3
